Dental Lab Micromotor For Drilling Polishing. Products Description: Product name – Dental Micro Motor. Model – AS-N8. Input Power – 100/240V. Output Power – DC 0-30V. Frequency – 50/60Hz. Export Markets – Global. Current Max – 3A. Maximum Speed – 0-45000rpm/Min. Handpiece type – Brush less handpiece. Handpiece size – L158 * 25mm. Gross weight – 3.45KG. Controller size – W83 * D290 * H240mm. Contoller weight – 2.9 KGS. Handpiece weight – 190 G. Maximum torque – 7.8 N.cm.
Compact sized control box with precise small & strong micro motor handpiece. Very High-powered and quality 0-45,000rpm. Tips size: 2.35mm. Tool exchange method using cam (twists the handle counter-clock wise to change the bur and can be easily restored back to the original position). Non stage speed system (it’s well designed to output from 0 to 45,000rpm by using non stage speed system). Right & Left turning ability. Foot ON/OFF switch system (Variable Control system using foot). Installed special ball bearings for super high speed(less heat and noise). Dust seal protection for excellent durability.
• Voltage: 220V/50Hz±10%
• Power: 100W
• Maximum Stall Current: 3A
• Motor maximum voltage: DC32V
• Speed range: 0 – 45,000 R.P.M
• Collet size: 3/32’’
• Bur size: 2.35mm
• Weight: 3.45KG
• Input Power: 100/240V
• Output Power: DC 0-30V
• Frequency: 50/60Hz
• Current Max: 3A
• Maximum Speed: 0-45000rpm/Min
• Handpiece type: Brush less handpiece
• Handpiece size: L158 * 25mm
• Gross weight: 3.45KG
• Controller size: W83 * D290 * H240mm
• Contoller weight: 2.9 KGS
• Handpiece weight: 190 G
• Maximum torque: 7.8 N.cm
• Compact sized control box
• Precise small & strong micro motor handpiece
• Very High-powered and quality 0-45,000rpm
• Tips size: 2.35mm
• Tool exchange method using cam
• Non stage speed system
• Right & Left turning ability
• Foot ON/OFF switch system
• Installed special ball bearings for super high speed
• Dust seal protection for excellent durability
